AS6C4008-55PIN
SRAM Chip Async Single 3.3V/5V 4M-Bit 512K x 8Bit 55ns 32-Pin PDIP
Click image to enlarge
Manufacturer:Alliance Memory
Avnet Manufacturer Part #: AS6C4008-55PIN
Secondary Manufacturer Part#: AS6C4008-55PIN
-
RoHS 10 Compliant -
Tariff Charges
The AS6C4008 is a 4,194,304-bit low power CMOS static random access memory organized as 524,288 words by 8 bits. It is fabricated using very high performance, high reliability CMOS technology. Its standby current is stable within the range of operating temperature.The AS6C4008 is well designed for very low power system applications, and particularly well suited for battery back-up non-volatile memory application. The AS6C4008 op erates from a sing le p owe r sup p ly of 2.7V~ 5.5Vand all inputs and outputs are fully TTL compatible.
- Access time : 55 ns
- Low power consumption:
- Operating current : 30 mA (TYP.)
- Standby current : 4 µA (TYP.)
- Single 2.7V ~ 5.5V power supply
- All outputs TTL compatible
- Fully static operation
- Tri-state output
- Data retention voltage :1.5V (MIN.)
- All products ROHS Compliant
- Package : 32-pin 450 mil SOP;32-pin 600 mil P-DIP
- 32-pin 8mm x 20mm TSOP-I
- 32-pin 8mm x 13.4mm STSOP
- 36-ball 6mm x 8mm TFBGA
- 32-pin 400 mil TSOP-II
Technical Attributes
Find Similar Parts
| Description | Value | |
|---|---|---|
| 19 Bit | ||
| SDR | ||
| 4 Mbit | ||
| 260 °C | ||
| 60 mA | ||
| 55 ns | ||
| 4 Mbit | ||
| Surface Mount | ||
| 32 | ||
| 8 Bit | ||
| 8 Bit | ||
| 1 | ||
| 512 kWords | ||
| -40 to 85 °C | ||
| 85 °C | ||
| -40 °C | ||
| 32PDIP | ||
| 32 | ||
| 41.91 x 13.843 x 3.937 mm | ||
| 0 | ||
| Industrial | ||
| PDIP | ||
| 5.5 V | ||
| 2.7 V | ||
| 3, 5 V | ||
| Asynchronous | ||
| 3.3, 5 V |
ECCN / UNSPSC / COO
| Description | Value |
|---|---|
| Country of Origin: | null |
| ECCN: | EAR99 |
| HTSN: | PARTS... |
| Schedule B: | PARTS... |
Factory Lead Time:
