60GHz radar sensors

The BGT60LTR11AIP is a fully integrated microwave motion sensor including Antennas in Package (AIP) as well as built-in detectors for motion and direction of motion. A state machine enables operation of the sensor without any external microcontroller.

The BGT60LTR11AIP enables radar technology for everyone, since it does not require know-how in RF, antenna design or radar signal processing. These features make the small sized radar solution a compelling smart and cost-effective replacement for conventional PIR sensors in low power or battery-powered applications.

Features

• 3.3 x 6.7 x 0.56 mm package size
• 1Tx 1Rx Antennas in Package (AIP) with 80° Half Power Beam-Width
• Built-in motion detector
• Built-in direction of motion detector
• Multiple modes of operation incl. a completely autonomous mode
• Adjustable performance parameters: detection sensitivity, hold time and frequency of operation
• FR4 material for PCB design

Target applications

• Smart home devices (Thermostats, smoke detectors, smart speakers, etc.)
• Smart building (Contactless switches, occupancy & proximity sensors, etc.)
• Smart appliances (Vacuum cleaners, kitchen appliances, etc.)
• Smart lighting systems
• Security systems including IP cameras
• Automated door openers
• Screen based systems (TV, notebook, tablet, etc.)
