Dialog configurable power solutions

Dialog provides a portfolio of configurable mixed-signal ICs (CMICs) to implement common power functions such as system protection, system reset, power sequencing, voltage monitoring, watchdog timer and more. The configurable nature of these products allows quick and low cost prototyping of ICs that are completely customized to your needs. Whether you are creating a design from scratch or making revisions to an existing design, CMICs are the best solutions for low cost, low power, highly integrated power functions.

The GreenPAK development platform and intuitive schematic capture GUI allows for fast and easy IC design and the ability to prototype in minutes. Download the Designer software to design your power ICs from scratch or modify existing design files for faster implementation.

Download GreenPAK designer software

View all products in the GreenPAK Product Portfolio



Power Sequencer with GreenPAK

Silego Technology, Power Sequencer

Successfully powering up a system can be tricky. So can powering one off. Timing, order of events, and power levels need to be just right for proper system functionality and stability. Using a power sequencer can also prevent unnecessary current draw while portions of the design sit idle, waiting for prerequisite systems to be powered. Some FPGAs may require more than ten rails, which if sequenced using discrete components, could introduce extra power and board space overhead.



Using the GreenPAK™ family of devices, it is easy to implement custom power sequencer designs in an extremely small area, using minimal power and board space. When paired with the tiny, ultra-low RDSON GreenFET™ Integrated Power Switch, power sequencing with Configurable Mixed-signal ICs is an incredibly efficient solution.



Reset IC

Silego Technology, Reset-IT

Electronics containing complex, code-based Integrated Circuits (ICs) are prone to lock-ups. This can lead to degraded user experience, damaged components, safety concerns and, ultimately, lower sales. One solution is to implement a hardware reset circuit which detects the lock-up and sends a hard reset signal to the locked-up IC.

GreenPAK™ is an ideal solution for a fully customizable system reset IC. Adding an additional layer of stability to systems is made easy with GreenPAK’s programmable digital and analog components in incredibly small packages. Since GreenPAK is entirely implemented in hardware, there is never any worry of lock-ups or missed events.



Supercap interface IC

Silego Technology, supercap

Supercapacitors are proliferating given their high energy density versus normal capacitors, low effective series resistance (ESR), and high durability compared to conventional batteries when it comes to repeated charging. To effectively design with supercapacitors, supporting interface circuitry is required for active cell balancing, power path management, voltage conversion, and other protection features unique to supercapacitors.



GreenPAK products are an ideal solution for performing many of these supporting functions to supercapacitor-based systems. Unlike dedicated ICs that are costly and specialized with limited capability, GreenPAK parts are competitively priced, can be quickly customized with programmable thresholds and timing, and eliminate many external setting components.



Integrated power switches with system protection

Using proprietary n-channel and p-channel MOSFET design and advanced assembly techniques, Dialog delivers an elite, feature-rich family of robust integrated power switches that achieve world-class RDSON, lowest leakage current per ohm RDSON, and highest current carrying capability per square mm.

The 2.5 V - 5.5 V GreenFET™3 family and the 4.5 V - 24 V HFET™1 family offer ultra-stable RDSON across a wide input/supply range while also integrating a comprehensive suite of protection features including.

Silego Technology, GFET
GreenFET Featured Products Description
SLG59M1714V A 4 mm², 4 A back-to-back nFET reverse blocking power control switch with Analog current-monitor output, fast VOUT discharge, and open-drain FAULT signaling output
SLG59M1735C A 10.5 mΩ, 4 A nFET IPS with Soft-start and Protection Features in a 1.5 mm² WLCSP
SLG59M1748C A Reverse-blocking, 35-mΩ, 2.2-A pFET IPS in a 0.64 mm² WLCSP
HFET Featured Products
SLG59H1302C A surge-protected, 28V tolerant USB Type C Power Splitter/Switch in WLCSP
SLG59H1005V A 4.8 mm² back-to-back reverse blocking power control switch with pin-selectable VIN overvoltage protection, internal 5W nFET SOA protection, and IDS Current Monitor Output
SLG59H1120V A 4.8 mm² power control switch with pin-selectable VIN overvoltage protection, internal 5W nFET SOA protection, and IDS Current Monitor Output


GreenPAK product portfolio

  SLG46108V SLG46125/7 SLG46116/7 SLG46110 SLG46120 SLG46140 SLG46169 SLG46170 SLG46534
# of GPIOs 6 6 7 8 10 12 12 12 12
Operating Voltage (V) 1.8 to 5.0 1.8 to 5.0 1.8 to 5.0 1.8 to 5.0 1.8 to 5.0 1.8 to 5.0 1.8 to 5.0 1.8 to 5.0
Analog/Digital Comparators 2/0 2/0 2/0 2/0 2/3 2/0 2/3
Look Up Tables (LUTs) 4 4 Total 4 Total 4 Total 5 Total 8 Total 9 Total 15 Total
Combination Function Macro-cells* 6 Total 6 Total 6 Total 6 Total 11 Total 8 Total 9 Total 2 Total 17 Total
Counters/Delays 3 3 3 3 2 2 5 8
  SLG46536 SLG46515/7 SLG46533 SLG46537 SLG46580 SLG46620 SLG4721 SLG46722 SLG46880
# of GPIOs 12 16 18 18 9 18 18 18 28
Operating Voltage (V) 1.8 to 5.0 1.8 to 5.0 1.8 to 5.0 1.8 to 5.0 1.8 to 5.0 1.8 to 5.0 1.8 to 5.0 1.8 to 5.0 2.5 to 5.0
Analog/Digital Comparators 3/0 4/0 4/0 4/0 4/0 6/3 4/0 5/0
Look Up Tables (LUTs) 1 25 Total 9 Total 15 Total
Combination Function Macro-cells* 24 Total 17 Total 24 Total 17 Total 15 Total 1 Total 9 Total 2 Total 12 Total
Counters/Delays 10 5 8

*Digital resources combining LUTs and DFFs, CNT/DLYs, etc.

Powering IoT Supercap Energy Harvesting Systems - Grid

Display portlet menu

Dialog Webinar Series

Powering IoT w/ Supercap Energy Harvesting Systems

3 part webinar series: Supercap backup solutions Toolkit – 9/29 Energy harvesting w/ supercaps – 10/25 Implementing Low Power IoT Devices w/ hybrid energy storage systems – 11/29 All webinars available OnDemand after live date.

Silego webinars, mouse, technology, circuit boards, paradigm

GreenPAK Development Software - Grid

Display portlet menu

Dialog

GreenPAK development software

Download the GreenPAK Designer software to design your power ICs from scratch or modify existing design files for faster implementation.

Silego Technology, GreenPak Designer

GreenPAK Programmable Mixed Signal Products - Grid

Display portlet menu

Dialog

GreenPAK programmable mixed signal products

The GreenPAK family is a cost effective one-time NVM programmable device that enables innovators to integrate many system functions while minimizing component count, board space and power consumption. See all GreenPAK Parts.

Silego Technology, GreenPak Component

GreenFET Integrated Power Switches - Grid

Display portlet menu

Dialog

GreenFET integrated power switches

The 2.5 V - 5.5 V GreenFET™ family offers ultra-stable RDSON across a wide input/supply range while also integrating a comprehensive suite of protection features. See all GreenFET Products!

Silego Technology, GreenFET

HFET Integrated Power Switch - Grid

Display portlet menu

Dialog

HFET integrated power switches

Dialog's family of high-performance integrated power switches includes high-voltage capability for all high-side, 4.5 V to 24 V power rail applications up to 6 A. See the entire portfolio!

Silego Technology, HFET
