New Product Introduction

STMicroelectronics STM32G4 series of mixed-signal MCUs

The STM32G4 Series combines a 32-bit Arm® Cortex®-M4 core with FPU and DSP instructions running at 170 MHz combined with 3 different hardware accelerators

STMicroelectronics STM32G4 product family picture

The STM32G4 Series combines a 32-bit Arm® Cortex®-M4 core (with FPU and DSP instructions) running at 170 MHz combined with 3 different hardware accelerators: ART Accelerator™, CCM-SRAM routine booster and mathematical accelerators.

STM32G4 Series consists of :

  • The STM32G4x1 Access line: general-purpose microcontrollers with an entry level set of analog peripherals
  • The STM32G4x3 Performance line: general-purpose microcontrollers with the maximum number of analog peripherals
  • The STM32G4x4 Hi-resolution line with high-resolution timer and complex waveform builder plus event handler (HRTIM) for digital power conversion, such as digital switched-mode power supplies, lighting, welding, solar and wireless charging


Key features

  • Rich advanced analog peripherals (comparator, op-amps, DAC)
  • Dual-bank Flash memory with error-correcting code (ECC) (supports in-field firmware upgrades)
  • USB Type-C interface with Power Delivery including physical layer (PHY)


Applications

  • Digital power supplies
  • Advanced motor controls
  • Lighting
  • Building-automation products


Hardware tools

  • NUCLEO-G431KB - STM32 Nucleo board
  • NUCLEO-G431RB - STM32 Nucleo-64 development board with STM32G431RB MCU, supports Arduino and ST morpho connectivity
  • P-NUCLEO-IHM03 - Motor Control Nucleo Pack with NUCLEO-G431RB and X-NUCLEO-IHM16M1
  • NUCLEO-G474RE - STM32 Nucleo-64 development board with STM32G474RE MCU, supports Arduino and ST morpho connectivity
  • STM32G474E-EVAL - Evaluation board with STM32G474QE MCU
  • STM32G474E-EVAL1 - Board with motor-control configuration board with solder bridge and resistor configuration
  • STM32G484E-EVAL - Evaluation board with STM32G484QE MCU



Image of stm32g4 series portfolio
