PAN1326C2 series Bluetooth® dual mode module

Panasonic’s new PAN1326C2 is a Host Controlled Interface (HCI) Bluetooth Radio Frequency (RF) module

Panasonic PAN1326C2 Series Bluetooth® Dual Mode Module

Panasonic’s new PAN1326C2 is a Host Controlled Interface (HCI) Bluetooth Radio Frequency (RF) module that brings Texas Instruments Incorporated™ seventh generation Bluetooth core integrated circuit, the C2564C, to an easy-to-use module format. The PAN1326C2 is Bluetooth 4.2 compliant and it offers best-in-class RF performance with about twice the range of other Bluetooth Low Energy solutions. Panasonic’s tiny footprint technology has produced a module of only 85.5 mm². The module is designed to accommodate PCBs pad pitch of 1.3 mm and as few as two layers for easy implementation and manufacturing. The module has been designed to be 100 percent pin-compatible with previous generations of Texas Instruments based Bluetooth HCI modules.
CE RED, FCC, IC certifications are available.



Features and benefits

  • Bluetooth-4.2-compliant up to the HCI layer
  • Best-in-class Bluetooth RF performance (Tx, Rx sensitivity, blocking)
  • Fully-qualified Bluetooth
  • Dimensions: 9.0 mm x 9.5 mm x 1.8 mm
  • Based upon TI’s CC2564C
  • Interfaces: UART, GPIO, PCM
